NX381 - 9" LED Mini Bar with 2 Point Bolt Mount

Skip to product information
1 of 5

Product Description:

LED Mini Bars are a staple safety product for light commercial vehicles. Whether they’re operating roadside or around a large mine site, these bars with their 12+ flash modes and industry leading approval ratings mean they are ready to bolt or stick onto your vehicle and go to work.

This NX381 is a 9" mini bar with two point bolt mount hardware.

To see the flash modes in action, click on the image below.


Warranty

3 Years

Kit Contents

1 x LED Mini Bar
2 x Foam vibration dampeners
2 x Stud bolts & nuts
2 x Spring & flat washers

Regular price $171.17 AUD
Sale price $171.17 AUD Regular price
Shipping calculated at checkout.
NX381 - 9" LED Mini Bar with 2 Point Bolt Mount

$171.17 AUD

  • Specifications

    • Weight: 740g
    • Mounting: Two point bolt mount
    • Wiring: 500mm hardwire fly lead
    Red: Positive
    Black: Negative
    Yellow: Mode Select

  • Range Wide Features & Specifications

    • Voltage: 12-24V (10-30V)
    • Twelve flash modes
    • Polycarbonate body & lens
    • Operating Temp: -30°C ~ +65°C
    • EMI Approvals:
    CISPR25 Class 3, ECE R10
    • Class Approvals:
    ECE R65 Class 1, SAEJ845 Class 1
    • Waterproof Ratings:
    Spray IP66, Submerge IP67
    • Maximum Current Draw:
    1.6A @ 13.8V, 0.9A @ 24V

  • Flash Modes

    1) Single Flash - ECE R65 Class 1 (125 FPM)
    2) Single Flash (75 FPM)
    3) Double Flash (125 FPM)
    4) Triple Flash (125 FPM)
    5) Rotating (125 FPM)
    6) Combination Single / Triple Flash
    7) Combination Single / Quint Flash
    8) Triple Flash - Alternating
    9) Triple Flash Alternating / Single Flash All
    10) Triple Flash Alternating / Single Flash All / Rotating
    11) Strobe (600FPM)
    12) Cruise / Solid On - 30% Brightness for night use
